SOT-223-5 VOLTAGE REGULATOR
EVALUATION BOARD USER ’S GUIDE
Chapter 1. Product Overview
1.1
1.2
INTRODUCTION
The SOT-223-5 Voltage Regulator Evaluation Board is designed to provide functional
evaluation of Microchip Voltage Regulators that utilize the SOT223-5 package and the
following device pinout:
Pin 1 = SHDN
Pin 2 = V IN
Pin 3 = GND
Pin 4 = V OUT
Pin 5 = PWRGD / ADJ
The SOT-223-5 Voltage Regulator Evaluation Board does not come with a voltage
regulator soldered onto the board. This allows the users to attach the voltage regulator
of their choosing to the board and perform quiescent current, ground current, PSRR,
and other desired tests.
The SOT-223-5 Voltage Regulator Evaluation Board is based upon a modulare concept
that will allow the user to plug in additional boards to increase the test capability of the
voltage regulator. Planned additional modulare plugin boards currently consist of an
Input Voltage Linestep Board, Output Voltage Loadstep Board, and several other
device packages.
WHAT IS THE SOT-223-5 VOLTAGE REGULATOR EVALUATION BOARD?
The SOT-223-5 Voltage Regulator Evaluation Board is designed to evaluate and test
voltage regulators. By soldering the desired device to the evaluation board, the user
can easily validate several parameters of the device.
1.2.1
Functional Blocks
The SOT-223-5 Voltage Regulator Evaluation Board can be broken up into 6 functional
blocks. The blocks are:
?
?
?
?
?
?
Input Capacitance
Shutdown Control
Ground Current Measurement
Voltage Adjust
Power Good
Load Resistor
1.2.2
Input Capacitance
Jumper JP1 connects the input capacitance to the circuit. The input capacitor is
disconnected when performing Power Supply Ripple Rejection tests. By default, C 1 is
populated with a 1 μF, 50V, XR7 ceramic capacitor.
? 2008 Microchip Technology Inc.
DS51751A-page 5
